Mounting, Installation & Operating Instructions :

• Can be used for both-Horizontal, Tilted and Vertical Type Mounting
• Suitable for enclosed mounting applications only
• Suitable Mounting Stand and Support Plate to be made for all kinds of mounting
• Copper Wire for winding to be of suitable gauge and flexible.
• Wire Wound Core must be well-fastened on Mounting Apparatus/Fixture
• Area of application must be Dust-Free for optimum performance.
• For Oil-immersed application, use only IEC-60296/ASTM D 3455-02 compatible oil

Typical Applications

• Common Mode Noise Suppression
• Motor-bearing current limitation in inverter-motor systems
• Cores for Inductors
• AC-DC Converters, Bi-directional DC-DC Converters
• DC Fast Chargers, DC Power Suppliers

Environmental Conditions and Storage/Handling Instructions

• Non-Hazardous Material.
• Item must be stored in a Cool and Well-Ventilated Area.
• Keep Away from Direct Sunlight or Exposure to Moisture.
• Item must be stored in its Original Packaging only.
• Storage Temperature: 20°C~45°C.
• Humidity: Average < 95%
• Delicate/Fragile Material. To be Handled with utmost Care.
• Do not mishandle/drop the Material. It can result in Core Failures.
• Use Standard P-U/Rubber/ or Suitable Gloves having reasonably good grip while Handling the material/unpacking/etc.
• Material is sealed inside Protective Insulated Housing for optimum performance. Never attempt to open the Housing.

Mean Life Expectancy

• Upto 130,000 Hours or 15 years, whichever is lesser.
• At the end of Service Life, product is to be de-energized and disconnected from its application and separately returned to Vikarsh in appropriately-packed condition for reprocessing within established standards.
• Dispose in accordance with local environmental regulations / WEEE directives.
• For Oil-immersed applications, product must be well-dried before being packed for return

Safety

• Disconnect the Nano-crystalline Core from the Electrical Circuit before Handling and Inspection
• Insulated Hand-gloves and necessary Protective Equipment must be be worn for Inspection
